| Nama | SEBUAH | B | C | D | E | F | G | H |
| ALAT BERSAMA: 1 | ||||||||
| 2 3/8 API Reguler | 2-3 / 8 " | 3-1 / 8 " | 2-5 / 8 " | 3 | 5 | 3 | API 60 ° | 1 |
| 2 7/8 API Reguler | 2-7 / 8 " | 3 3/4 | 3 | 3 1/2 | 5 | 3 | API 60 ° | 1 1/4 |
| 3 1/2 API Reguler | 3 1/2 | 4 1/4 | 3 1/2 | 3 3/4 | 5 | 3 | API 60 ° | 1 1/2 |
| 4 1/2 API Reguler | 4 1/2 | 5 1/2 | 4-5 / 8 " | 4 1/4 | 5 | 3 | API 60 ° | 1 1/4 |
| 2 3/8 API Internal Flush | 2-3 / 8 " | 3-3 / 8 " | 2-7 / 8 " | 3 | 4 | 2 | API 60 ° | 1 3/4 |
| 2 7/8 API Internal Flush | 2-7 / 8 " | 4-1 / 8 " | 3 25/64 | 3 1/2 | 4 | 2 | API 60 ° | 2-1 / 8 " |
| 3 1/2 API Internal Flush | 3 1/2 | 4 3/4 | 4 1/64 | 4 | 4 | 2 | API 60 ° | 2 11/16 |
| 2 3/8 Mayhew Junior | 2-3 / 8 " | 2 3/4 | 2 21/64 | 2 1/4 | 4 | 2 | 60 ° Mod. API | 1 1/2 |
| 2 3/8 Mayhew Reguler | 2-3 / 8 " | 3 1/4 | 2 35/64 | 3 | 4 | 1 1/2 | 60 ° Mod. API | 1-5 / 8 " |
| 2 7/8 Mayhew Full Hole | 2-7 / 8 " | 3 3/4 | 3 3/64 | 3-3 / 8 " | 4 | 1 1/2 | 60 ° Mod. API | 2 |
| 2 3/8 Gagal Eksplorasi | 2-3 / 8 " | 2 31/32 | 2 1/2 | 2 3/4 | 4 | 2 | 60 ° Mod. API | 1 1/2 |
| 2 7/8 Gagal Eksplorasi | 2-7 / 8 " | 3 3/4 | 3-1 / 8 " | 3 1/4 | 4 | 2 | 60 ° Mod. API | 1-7 / 8 " |
| 2 3/8 Hughes Acme Reguler | 2-3 / 8 " | 3-1 / 8 " | 219/32 | 3 | 4 | 3-3 / 8 " | 29 ° Acme | 1 |
| 2 3/8 Musim Dingin Weiss | 2-3 / 8 " | 3 1/4 | 235/64 | 3 | 4 | 1 1/2 | 60 ° Mod. API | 1 1/2 |
| 2 7/8 Musim Dingin Weiss | 2-7 / 8 " | 37/16 | 235/64 | 3 | 4 | 1 1/2 | 60 ° Mod. API | 1 1/2 |
| 3 1/2 API Lubang Penuh | 3 1/2 | 4-5 / 8 " | 4 | 3 3/4 | 5 | 3 | 60 ° Mod. API | 27/16 |
| FLUSH JOINT TAPERED THREAD | ||||||||
| United Geophysical (1 11/16 OD) | 111/16 | 111/16 | 1-3 / 8 " | 1 | 6 | 3 | 29 ° Acme | 1 |
| Deskripsi | OD pipa | Dinding Pipa | OD koneksi | ID Sambungan | Panjang (ft) |
| 2-3 / 8 JIKA Siram | 3 1/2 | 0,375 | 3 1/2 | 1 3/4 | 20 |
| 2-3 / 8 JIKA | 2 3/8 | .280 / 254 | 3 1/2 | 1 3/4 | 10, 15, 20 |
| 2-3 / 8 FEDP | 2 3/8 | .280 / 254 | 3 1/8 | 1 1/2 | 10, 15, 20 |
| 2-3 / 8 Mayhew Jr | 2 3/8 | .280 / 254 | 3 | 1 1/2 | 10, 15, 20 |
| 2-3 / 8 Mayhew Jr | 2 3/8 | 0,19 | 2 3/4 | 1 1/2 | 5, 10 |
| 2-7 / 8 Mayhew Jr Pipe Flush | 2 7/8 | 0,362 | 2 7/8 | 1 1/2 | 10, 15, 20 |
| Mayhew Reg. Menyiram | 3 1/2 | 0,375 | 3 1/2 | 1 1/2 | 20 |
| Mayhew Reg. | 2 3/8 | .280 / 254 | 3 1/2 atau 3 1/4 | 1 1/2 | 10, 15, 20 |
| 2-7 / 8 JIKA | 4 1/2 | 0,337 | 4 1/8 | 2 1/2 | 10, 15, 20 |
| 3-1 / 2 JIKA | 5 1/2 | 0,362 | 4 3/4 | 2 11/16 | 10, 15, 20 |
| 3-1 / 2 API Reg Flush | 4 1/2 | 0,337 | 4 1/2 | 1 1/2 | 10, 15, 20 |
| 4-1 / 2 API Reg Flush | 5 1/2 | .362 / .478 | 5 1/2 | 2 1/4 | 10, 15, 20 |
| AWJ / AW w / Flats | 1 3/4 | .188 / .250 | 1 3/4 | 5/8 | 5,10 |
| NWJ / NW w / Flat | 2 5/8 | .188 / .250 | 2 5/8 | 1-1 / 4 atau 1-3 / 8 | 5,10 |
| Alat Sambungan Bersama | Mayhew JR, Mayhew Reg, 2-3 / 8 "FEDP, 2-7 / 8" FEDP, AWJ, NWJ, 2-7 / 8 "IF, 3-1 / 2" IF, 3-1 / 2 "API Reg , 4-1 / 2 "API Reg, 2-3 / 8" IF |
| OD pipa | 2-3 / 8 ", 2-7 / 8", 3-1 / 2 ", 4-1 / 2", 5-1 / 2 ", 1-3 / 4", 2-5 / 8 " |
| Ketebalan Dinding Pipa | .190, .188, .250, .254, .276, .280, .337, .362, .368, .478 |
| Panjang Gabungan | 5 ', 10', 15 ', 20' |
| Alat Breakout | Flat, Lug, Tidak ada |
