Pipa Bor 4 1/2”, 16,6 Lb ft, S-135, Sambungan NC-46
Pipa Bor dan Pipa Bor Berat Berat
Pipa bor kami sesuai dengan API Spec 5D dan pipa bor berat kami sesuai dengan API Spec 7-1.Kami menyediakan berbagai ukuran API penuh untuk pipa bor dan pipa bor berat dari 2-3/8 hingga 6-5/8 inci.Pipa bor berat kami mencakup pipa bor berat integral dan pipa bor berat yang dilas.Nilai baja pipa bor kami termasuk E75, X95, G105 dan S135.Selain itu, kami dapat menambahkan hardbanding dan pelapis internal berdasarkan permintaan.Kami juga menjual berbagai macam tool joint dan aksesoris drill stem diantaranya pup joint, lift sub, crossover sub, dan reamer dll.
Selain pipa bor, kerah bor, casing dan tubing oli, dan pipa saluran, kami menyediakan rig pengeboran, rig workover, top drive, peralatan pengeboran, pompa lumpur tripleks, pencegah ledakan, sistem kontrol BOP, peralatan kontrol padatan, dll. Silakan kunjungi situs web perusahaan kami atau unduh katalog lengkap kami untuk melihat lini produk lengkap kami.
| Pipa | Sambungan Alat | |||||||||
| Ukuran OD, | Berat Nominal, | Tipe Kesal | Nilai | Ketebalan dinding, | PENGENAL, | Jenis Koneksi | sekarang, | PENGENAL, | Ruang Pin Tong*, | Kotak Tong Ruang*, |
| di dalam. | lb/ft | di dalam. | di dalam. | di dalam. | di dalam. | di dalam. | di dalam. | |||
| 2 3/8 | 6.65 | UE | E-75 | 0,28 | 1.815 | NC26 | 3 3/8 | 1 3/4 | 9 | 10 |
| X-95 | 0,28 | 1.815 | NC26 | 3 3/8 | 1 3/4 | 9 | 10 | |||
| G-105 | 0,28 | 1.815 | NC26 | 3 3/8 | 1 3/4 | 9 | 10 | |||
| S-135 | 0,28 | 1.815 | NC26 | 3 5/8 | 1 3/4 | 9 | 10 | |||
| 2 7/8 | 10.4 | UE | E-75 | 0,362 | 2.151 | NC31 | 4 1/8 | 2 1/8 | 9 | 11 |
| X-95 | 0,362 | 2.151 | NC31 | 4 1/8 | 2 | 9 | 11 | |||
| G-105 | 0,362 | 2.151 | NC31 | 4 1/8 | 2 | 9 | 11 | |||
| S-135 | 0,362 | 2.151 | NC31 | 4 3/8 | 1 5/8 | 9 | 11 | |||
| 3 1/2 | 13.3 | UE | E-75 | 0,368 | 2,764 | NC38 | 4 3/4 | 2 11/16 | 10 | 12 1/2 |
| X-95 | 0,368 | 2,764 | NC38 | 5 | 2 9/16 | 10 | 12 1/2 | |||
| G-105 | 0,368 | 2,764 | NC38 | 5 | 2 7/16 | 10 | 12 1/2 | |||
| S-135 | 0,368 | 2,764 | NC38 | 5 | 2 1/8 | 10 | 12 1/2 | |||
| 15.5 | UE | E-75 | 0,449 | 2.602 | NC38 | 5 | 2 9/16 | 10 | 12 1/2 | |
| X-95 | 0,449 | 2.602 | NC38 | 5 | 2 7/16 | 10 | 12 1/2 | |||
| G-105 | 0,449 | 2.602 | NC38 | 5 | 2 1/8 | 10 | 12 1/2 | |||
| S-135 | 0,449 | 2.602 | NC40 | 5 1/2 | 2 1/4 | 9 | 12 | |||
| 4 | 14 | IU | E-75 | 0.33 | 3.34 | NC40 | 5 1/4 | 2 13/16 | 9 | 12 |
| X-95 | 0.33 | 3.34 | NC40 | 5 1/4 | 2 11/16 | 9 | 12 | |||
| G-105 | 0.33 | 3.34 | NC40 | 5 1/2 | 2 7/16 | 9 | 12 | |||
| S-135 | 0.33 | 3.34 | NC40 | 5 1/2 | 2 7/16 | 9 | 12 | |||
| UE | E-75 | 0.33 | 3.34 | NC46 | 6 | 3 1/4 | 9 | 12 | ||
| X-95 | 0.33 | 3.34 | NC46 | 6 | 3 1/4 | 9 | 12 | |||
| G-105 | 0.33 | 3.34 | NC46 | 6 | 3 1/4 | 9 | 12 | |||
| S-135 | 0.33 | 3.34 | NC46 | 6 | 3 | 9 | 12 | |||
| 15.7 | IU | E-75 | 0.38 | 3.24 | NC40 | 5 1/4 | 2 11/16 | 9 | 12 | |
| X-95 | 0.38 | 3.24 | NC40 | 5 1/4 | 2 7/16 | 9 | 12 | |||
| G-105 | 0.38 | 3.24 | NC40 | 5 1/2 | 2 7/16 | 9 | 12 | |||
| S-135 | 0.38 | 3.24 | NC40 | 5 1/2 | 2 | 9 | 12 | |||
| UE | E-75 | 0.38 | 3.24 | NC46 | 6 | 3 1/4 | 9 | 12 | ||
| X-95 | 0.38 | 3.24 | NC46 | 6 | 3 1/4 | 9 | 12 | |||
| G-105 | 0.38 | 3.24 | NC46 | 6 | 3 1/4 | 9 | 12 | |||
| S-135 | 0.38 | 3.24 | NC46 | 6 | 3 | 9 | 12 | |||
| 4 1/2 | 16.6 | IEU | E-75 | 0,337 | 3.826 | NC46 | 6 1/4 | 3 | 9 | 12 |
| X-95 | 0,337 | 3.826 | NC46 | 6 1/4 | 3 1/4 | 9 | 12 | |||
| G-105 | 0,337 | 3.826 | NC46 | 6 1/4 | 3 | 9 | 12 | |||
| S-135 | 0,337 | 3.826 | NC46 | 6 1/4 | 2 3/4 | 9 | 12 | |||
| UE | E-75 | 0,337 | 3.826 | NC50 | 6 5/8 | 3 3/4 | 9 | 12 | ||
| X-95 | 0,337 | 3.826 | NC50 | 6 5/8 | 3 3/4 | 9 | 12 | |||
| G-105 | 0,337 | 3.826 | NC50 | 6 5/8 | 3 3/4 | 9 | 12 | |||
| S-135 | 0,337 | 3.826 | NC50 | 6 5/8 | 3 1/2 | 9 | 12 | |||
| 20 | IEU | E-75 | 0,43 | 3.64 | NC46 | 6 1/4 | 3 | 9 | 12 | |
| X-95 | 0,43 | 3.64 | NC46 | 6 1/4 | 2 3/4 | 9 | 12 | |||
| G-105 | 0,43 | 3.64 | NC46 | 6 1/4 | 2 1/2 | 9 | 12 | |||
| S-135 | 0,43 | 3.64 | NC46 | 6 1/4 | 2 1/4 | 9 | 12 | |||
| UE | E-75 | 0,43 | 3.64 | NC50 | 6 5/8 | 3 5/8 | 9 | 12 | ||
| X-95 | 0,43 | 3.64 | NC50 | 6 5/8 | 3 1/2 | 9 | 12 | |||
| G-105 | 0,43 | 3.64 | NC50 | 6 5/8 | 3 1/2 | 9 | 12 | |||
| S-135 | 0,43 | 3.64 | NC50 | 6 5/8 | 3 | 9 | 12 | |||
| 5 | 19.5 | IEU | E-75 | 0,362 | 4.276 | NC50 | 6 5/8 | 3 3/4 | 9 | 12 |
| X-95 | 0,362 | 4.276 | NC50 | 6 5/8 | 3 1/2 | 9 | 12 | |||
| G-105 | 0,362 | 4.276 | NC50 | 6 5/8 | 3 1/4 | 9 | 12 | |||
| S-135 | 0,362 | 4.276 | NC50 | 6 5/8 | 2 3/4 | 9 | 12 | |||
| E-75 | 0,362 | 4.276 | 5-1/2 FH | 7 | 3 3/4 | 10 | 12 | |||
| X-95 | 0,362 | 4.276 | 5-1/2 FH | 7 | 3 3/4 | 10 | 12 | |||
| G-105 | 0,362 | 4.276 | 5-1/2 FH | 7 | 3 3/4 | 10 | 12 | |||
| S-135 | 0,362 | 4.276 | 5-1/2 FH | 7 1/4 | 3 1/2 | 10 | 12 | |||
| 25.6 | IEU | E-75 | 0,5 | 4 | NC50 | 6 5/8 | 3 1/2 | 9 | 12 | |
| X-95 | 0,5 | 4 | NC50 | 6 5/8 | 3 | 9 | 12 | |||
| G-105 | 0,5 | 4 | NC50 | 6 5/8 | 2 3/4 | 9 | 12 | |||
| S-135 | 0,5 | 4 | NC50 | 6 5/8 | 2 3/4 | 9 | 12 | |||
| E-75 | 0,5 | 4 | 5-1/2 FH | 7 | 3 1/2 | 10 | 12 | |||
| X-95 | 0,5 | 4 | 5-1/2 FH | 7 | 3 1/2 | 10 | 12 | |||
| G-105 | 0,5 | 4 | 5-1/2 FH | 7 1/4 | 3 1/2 | 10 | 12 | |||
| S-135 | 0,5 | 4 | 5-1/2 FH | 7 1/4 | 3 1/4 | 10 | 12 | |||
| 5 1/2 | 21.9 | IEU | E-75 | 0.361 | 4.778 | 5-1/2 FH | 7 | 4 | 10 | 12 |
| X-95 | 0.361 | 4.778 | 5-1/2 FH | 7 | 3 3/4 | 10 | 12 | |||
| G-105 | 0.361 | 4.778 | 5-1/2 FH | 7 1/4 | 3 1/2 | 10 | 12 | |||
| S-135 | 0.361 | 4.778 | 5-1/2 FH | 7 1/4 | 3 | 10 | 12 | |||
| 24.7 | IEU | E-75 | 0,415 | 4.67 | 5-1/2 FH | 7 | 4 | 10 | 12 | |
| X-95 | 0,415 | 4.67 | 5-1/2 FH | 7 1/4 | 3 1/2 | 10 | 12 | |||
| G-105 | 0,415 | 4.67 | 5-1/2 FH | 7 1/4 | 3 1/2 | 10 | 12 | |||
| S-135 | 0,415 | 4.67 | 5-1/2 FH | 7 1/2 | 3 | 10 | 12 | |||
| 6 5/8 | 25.2 | IEU | E-75 | 0.33 | 5.965 | 6-5/8 FH | 8 | 5 | 10 | 13 |
| X-95 | 0.33 | 5.965 | 6-5/8 FH | 8 | 5 | 10 | 13 | |||
| G-105 | 0.33 | 5.965 | 6-5/8 FH | 8 1/4 | 4 3/4 | 10 | 13 | |||
| S-135 | 0.33 | 5.965 | 6-5/8 FH | 8 1/2 | 4 1/4 | 10 | 13 | |||
| 27.7 | IEU | E-75 | 0,362 | 5.901 | 6-5/8 FH | 8 | 5 | 10 | 13 | |
| X-95 | 0,362 | 5.901 | 6-5/8 FH | 8 1/4 | 4 3/4 | 10 | 13 | |||
| G-105 | 0,362 | 5.901 | 6-5/8 FH | 8 1/4 | 4 3/4 | 10 | 13 | |||
| S-135 | 0,362 | 5.901 | 6-5/8 FH | 8 1/2 | 4 1/4 | 10 | 13 | |||
Kerah Bor dan Kerah Bor Non-Magnetik
Kerah bor dibuat dengan bahan AISI 4145H sesuai dengan API Spec 7-1.Kami menyediakan kerah bor licin dan kerah bor spiral;ukuran mereka dari 3-1/8 sampai 11 inci.
Casing dan Tabung
Casing dan tubing ladang minyak kami sesuai dengan API Spec 5CT.Casing digunakan untuk pengeboran sumur minyak dan gas, dan tubing digunakan untuk mengekstraksi minyak dan gas dari reservoir.Casing oli kami mencakup casing mulus dan casing ERW.
pipa saluran
Pipa saluran digunakan untuk mengangkut minyak dan gas, air, bubur mineral dan cairan lainnya.Pipa saluran kami diproduksi sesuai dengan API Spec 5L.Kami menyediakan berbagai pipa saluran termasuk SSAW, LSAW, ERW dan pipa saluran mulus.
