Wireline Casing Advancer Borehole Systems dengan seumur hidup HWT Casing Shoe
Fitur:
• Tiga komponen utama meliputi pengemudi, inner assembly, dan inner
lengan pemuatan perakitan
• Pengikat positif memberikan metode pengeboran satu langkah yang efisien
melalui overburden dan casing ke batuan dasar.
• Penghapusan dan penggantian yang cepat dan mudah.
• Titik ujung tombak kompatibel dengan kelebihan NQ untuk menurunkan dan
pengambilan.
• Driver disertakan dengan koneksi kotak casing NW.
Aplikasi:
• Sampling tanah dan corong overburden bersamaan dengan casing.
• Casing melalui overburden atau formasi yang sulit.
Wireline Casing Advancer Inner Assembly
Tidak | Deskripsi | Qty | Wireline Casing Advancer Inner Assembly Parts Number | |||||||
BW | NW | HWT | PWT | |||||||
| 1 | Mempelopori | 1 | 2110085 | 2110085 | 9110215 | 9110215 | 9110215 | 9110215 | 9110215 | 9110215 |
| 2 | Disc Lock Washer | 1 | 2110090 | 2110090 | 6110350 | 6110350 | 6110350 | 6110350 | 6110350 | 6110350 |
| 3 | Release Shaft | 1 | 2110095 | 2110095 | 8110455 | 8110455 | 8110455 | 8110455 | 8110455 | 8110455 |
| 4 | Latch body | 1 | 2110100 | 2110100 | 3110165 | 3110165 | 4110230 | 4110230 | 5110295 | 5110295 |
| 5 | Sepatu latch | 2 | 2110105 | 2110105 | 3110170 | 3110170 | 4110235 | 4110235 | 5110300 | 5110300 |
| 6 | Latch Shoe Spring | 2 | 2110110 | 2110110 | 5110305 | 5110305 | 5110305 | 5110305 | 5110305 | 5110305 |
| 7 | Lokasi Pin | 2 | 2110115 | 2110115 | 6110375 | 6110375 | 6110375 | 6110375 | 6110375 | 6110375 |
| 8 | Stop Latch Set | 1 | 2110120 | 2110120 | 3110185 | 3110185 | 4110250 | 4110250 | 5110315 | 5110315 |
| 9 | Hentikan latch pin | 1 | 2110125 | 2110125 | 3110190 | 3110190 | 4110255 | 4110255 | 5110320 | 5110320 |
| 10 | Split Cotter Pin | 2 | 4110260 | 4110260 | 4110260 | 4110260 | 4110260 | 4110260 | 4110260 | 4110260 |
| 11 | Berhenti latch musim semi | 1 | 5110330 | 5110330 | 5110330 | 5110330 | 5110330 | 5110330 | 5110330 | 5110330 |
| 12 | Spacer Set | 1 | 2110140 | 2110140 | 3110205 | 3110205 | 4110270 | 4110270 | 5110335 | 5110335 |
| 13 | Bit Sub | 1 | 2110145 | 2110145 | 3110210 | 3110210 | 4110275 | 4110275 | 5110340 | 5110340 |
| 14 | Memuat Lengan | 1 | 2110038 | 2110038 | 3110000 | 3110000 | 4110042 | 4110042 | 5110028 | 5110028 |
| 15 | Sopir | 1 | 2110037 | 3110005 | 4110004 | 5110031 | ||||
| 16 | Sepatu Casing yang Luar Biasa | 1 | 2197178 | 3197100 | 4197128 | 5197132 | ||||
| 17 | Tricone Roller Bit | 1 | 2197179 | 3198058 | 4198063 | 5197152 | | |||
Roschen Inc. terus berusaha memperbaiki produknya dan karenanya harus memiliki hak untuk mengubah desain, bahan, spesifikasi dan harga tanpa pemberitahuan.
