Matrix 9 Grade HQ HQ3 HWL Impregnated Diamond Core Bits Longer Lifespan For Cut Quartz
ROSCHEN's 7 grade bits cuts through quartz and all types of granite or equivalent hardness rocks without any problem, and is well adapted to softer and abrasive ground.
Exploration Drilling Products:
The impregnated diamond bits are the most commonly useful bits in the mineral exploration industry, as they have the widest range of application. The carefully selected grades of high quality synthetic diamond are distributed in the depth of impregnated bit's matrix series. The matrix layer of the crown contains a uniform distribution of these crystals that are embedded in a powdered metal bond. The matrix of our impregnated bits is designed to expose new diamonds to the bits' cutting face as wear occurs. Fast penetration rate is maintained as a result of this action. Our impregnated bits are manufactured to give optimum penetration rates and bit life, which is required to keep the cost of diamond drilling to a minimum. The optimum diamond size, concentration and matrix type are dependent on the hardness and abrasiveness of the formation to be drilled. When order, please read.
Brief Introductions of Impregnated Diamond Bits:
The impregnated diamond bits are cutting tools. They contain diamond segments bonded to a base material. They are widely applied in cutting non-ferrous materials. The selected grades of synthetic diamond of high quality are distributed in the depth of impregnated bit's matrix series. The matrix layer of the crown contains a uniform distribution of these crystals that are embedded in a powdered metal bond. This diamond tool is widely applied in the mineral exploration industry.
Features of Impregnated Diamond Bits:
1. This diamond tool features with fast penetration rate, because the matrix of our impregnated diamond bits is specially designed (it is designed to expose new diamonds to the bits' cutting face as wear occurs).
2. Can help reduce the cost for diamond drilling: our impregnated diamond bits are manufactured to give optimum penetration rates and service life.
3. The hardness and abrasiveness of the formation to be drilled largely determined the optimum diamond size, concentration and matrix type, etc.
Available Size for our Impregnated Diamond Bits:
|Q Wireline series:||AQ, BQ, NQ, HQ, PQ/AQTK, BQTK, BQ3, NQ2, NQ3, NQTT, HQ3, HQTT, PQ3, PQTT|
|T2 series:||T2 46, T2 56, T2 66, T2 76, T2 86, T2 101, T2 116, T2 131|
|T6 series:||T6 76, T6 86, T6 101, T6 116, T6 131, T6 146, T6S 101, T6S 116|
|T series:||T36, T46, T56, T66, T76, T86, T101, T116, T131|
|Z series:||Z46, Z56, Z66, Z76, Z86, Z101, Z116, Z131, Z146|
|B series:||B36, B46, B56, B66, B76, B86, B101, B116, B131, B146|
|WF series:||HWF, PWF, SWF, UWF, ZWF|
|WT series:||RWT, EWT, AWT, BWT, NWT, HWT, PWT|
|WM series:||EWM, AWM, BWM, NWM, HWM|
|WG series:||EWG, AWG, BWG, NWG, HWG|
|QWL series:||AQWL, BQWL, NQWL, HQWL, PQWL, NQWL2, NQWL3, NQTT, HQWL3, HQTT,
|Others:||NMLC, HMLC, LTK48, LTK60, BGM, NGM, ADBG, TBW, TNW, ATW, BTW, NTW,
NXD3, EX, AX, BX, NX, NXC, EXT, AXT, EXU, AXU, NXU, T6H, 4-9/16, NWD4, 412F,
SK6L146, K2-101, K2-116, TT46, TB56, TS116, CHD101
Please feel free to send us your inquiries & requirements by firstname.lastname@example.org ; email@example.com .
|Kontak Person :||Mr. Bill, George, Michael|
