Atlas Copco Secoroc RC Bits and Shrouds Untuk RE035 Hammer Size 3 "
BIT SIRKULASI MUNDUR
Kualitas bit Roschen Reverse Circulation Hammer dapat diganti dengan Boart Longyear, atlas copco, halco, mincon, numa berdasarkan kualitas kelas, dan dalam layanan purna jual.
Rangkaian mata bor RC Sirkulasi Terbalik Roschen berkualitas tinggi dirancang khusus untuk bekerja dengan Palu RC kami.Karena mekanisme penyegelan mata bor kami, masalah kontaminasi sampel tidak menjadi masalah.Menggunakan desain 12 spline shank kami yang unik, RC Bit ini memberikan kinerja dan keandalan yang luar biasa.
Fitur:
1. Menggunakan karbida kelas yang lebih tinggi untuk hidup lebih lama;
2. Meminimalkan erosi lubang pada formasi yang rapuh
3. Mengebor lebih cepat melalui formasi lunak dengan lebih sedikit penyumbatan
4. Mengebor lurus melalui formasi terkonsolidasi dan tidak terkonsolidasi
ASORTMEN BIT | |||
Bagian no. | Ukuran mm | Ukuran inci | Kain kafan yang direkomendasikan |
RE035 | |||
63-035-306DC | 85,7 | 3 3/8 | 40- [] -305 |
63-035-308HF | 88,9 | 3 112 | 40- [] -307 |
63-035-400DC | 101,6 | 4 | 40- [] -400 |
Rakitan bit termasuk selubung yang diperkeras (tidak dilapisi) 1,6 mm (1/16 inci) lebih kecil dari diameter bit | |||
KALUNG KERAS | |||
Bagian no. | Ukuran mm | Ukuran inci | |
40-035-305 | 84,1 | 3 5/16 | |
40-035-306 | 85,7 | 3 3/8 | |
40-035-307 | 87,3 | 3 7/16 | |
40-035-308 | 88,9 | 31/2 | |
40-035-309 | 90,5 | 3 9/16 | |
40-035-310 | 92,1 | 3 5/8 | |
40-035-311 | 93,7 | 311/16 | |
40-035-315 | 100 | 315/16 |
Spesifikasi ROSCHEN Reverse Circulation Bits | ||||||||
RE531 RC bit | ||||||||
Kode ROSCHEN: ROS RC 30 | ||||||||
Diameter | Tidak ada x Diameter tombol mm | Sudut tombol | Lubang flusing | Shroud Dia mm | Berat (kg) | Bagian No | ||
mm | inci | Tombol Pengukur | Tombol Depan | |||||
86 | 3 3/8 | 6x12 | 4x12 | 35 | 2 | 84 | 4.2 | RE531-86 |
89 | 3 1/2 | 8x12 | 8x12 | 35 | 2 | 87 | 4.3 | RE531-89 |
95 | 3 3/4 | 8x12 | 8x12 | 35 | 2 | 93 | 4.6 | RE531-95 |
102 | 4 | 8x12 | 8x12 | 35 | 2 | 100 | 4.9 | RE531-102 |
RE004 RC bit | ||||||||
Kode ROSCHEN: ROS RC 40 | ||||||||
Diameter | Tidak ada x Diameter tombol mm | Sudut tombol | Lubang flusing | Shroud Dia mm | Berat (kg) | Bagian No | ||
mm | inci | Tombol Pengukur | Tombol Depan | |||||
114 | 4 1/2 | 8x14 | 6x14 | 35 | 2 | 112 | 11.5 | RE004-114 |
118 | 4 5/8 | 8x14 | 6x14 | 35 | 2 | 116 | 11.7 | RE004-118 |
121 | 4 3/4 | 8x14 | 6x14 | 35 | 2 | 119 | 12 | RE004-121 |
127 | 5 | 8x14 | 8x14 | 35 | 2 | 125 | 12.4 | RE004-127 |
RE542 | ||||||||
Kode ROSCHEN: ROS RC 50 | ||||||||
Diameter | Tidak ada x Diameter tombol mm | Sudut tombol | Lubang flusing | Shroud Dia mm | Berat (kg) | Bagian No | ||
mm | inci | Tombol Pengukur | Tombol Depan | |||||
121 | 4 3/4 | 8x14 | 6x14 | 35 | 2 | 119 | 10.6 | RE542-121 |
124 | 4 7/8 | 8x14 | 8x13 | 35 | 2 | 122 | 10.8 | RE542-124 |
127 | 5 | 8x14 | 8x14 | 35 | 2 | 125 | 11 | RE542-127 |
130 | 5 1/8 | 8x14 | 10x14 | 35 | 2 | 128 | 11.3 | RE542-130 |
RE543 | ||||||||
Kode ROSCHEN: ROS RC 50 | ||||||||
Diameter | Tidak ada x Diameter tombol mm | Sudut tombol | Lubang flusing | Shroud Dia mm | Berat (kg) | Bagian No | ||
mm | inci | Tombol Pengukur | Tombol Depan | |||||
124 | 4 7/8 | 8x14 | 8X13 | 35 | 2 | 122 | 10.8 | RE543-124 |
127 | 5 | 8x14 | 8X14 | 35 | 2 | 125 | 11 | RE543-127 |
130 | 5 1/8 | 8x14 | 10X14 | 35 | 2 | 128 | 11.3 | RE543-130 |
133 | 5 1/4 | 8x16 | 10X14 | 35 | 2 | 131 | 11.8 | RE543-133 |
RE545 | ||||||||
Kode ROSCHEN: ROS RC 50 | ||||||||
Diameter | Tidak ada x Diameter tombol mm | Sudut tombol | Lubang flusing | Shroud Dia mm | Berat (kg) | Bagian No | ||
mm | inci | Tombol Pengukur | Tombol Depan | |||||
124 | 4 7/8 | 8x14 | 8X13 | 35 | 2 | 122 | 13.3 | RE545-124 |
127 | 5 | 8x14 | 8X14 | 35 | 2 | 125 | 13.5 | RE545-127 |
133 | 5 1/4 | 8x16 | 10X14 | 35 | 2 | 131 | 13.8 | RE545-133 |
136 | 5 3/8 | 8x16 | 6x16 + 3x14 | 35 | 2 | 134 | 14.2 | RE545-136 |
Bit PR40 RC | ||||||||
Kode ROSCHEN: ROS RC 50 | ||||||||
Diameter | Tidak ada x Diameter tombol mm | Sudut tombol | Lubang flusing | Shroud Dia mm | Berat (kg) | Bagian No | ||
mm | inci | Tombol Pengukur | Tombol Depan | |||||
124 | 4 7/8 | 8x14 | 8X13 | 35 | 2 | 122 | 14.3 | PR40-124 |
127 | 5 | 8x14 | 8X14 | 35 | 2 | 125 | 14.7 | PR40-127 |
133 | 5 1/4 | 8x16 | 10X14 | 35 | 2 | 131 | 15.2 | PR40-133 |
138 | 5 4/9 | 8x16 | 6x16 + 3x14 | 35 | 2 | 136 | 15.8 | PR40-138 |
PR52 RC bit | ||||||||
Kode ROSCHEN: ROS RC 55 | ||||||||
Diameter | Tidak ada x Diameter tombol mm | Sudut tombol | Lubang flusing | Shroud Dia mm | Berat (kg) | Bagian No | ||
mm | inci | Tombol Pengukur | Tombol Depan | |||||
133 | 5 1/4 | 8x16 | 10x14 | 35 | 2 | 131 | 11.2 | PR52-133 |
136 | 5 3/8 | 8x16 | 6x16 + 3x14 | 35 | 2 | 134 | 11.5 | PR52-136 |
140 | 5 1/2 | 8x16 | 6x16 + 3x14 | 35 | 2 | 138 | 11.9 | PR52-140 |
143 | 5 5/8 | 8x16 | 6x16 + 3x14 | 35 | 2 | 141 | 12.3 | PR52-143 |
RE547 RC bit | ||||||||
Kode ROSCHEN: ROS RC 55 | ||||||||
Diameter | Tidak ada x Diameter tombol mm | Sudut tombol | Lubang flusing | Shroud Dia mm | Berat (kg) | Bagian No | ||
mm | inci | Tombol Pengukur | Tombol Depan | |||||
136 | 5 3/8 | 8x16 | 6x16 + 3x14 | 35 | 2 | 134 | 15.1 | RE547-136 |
140 | 5 1/2 | 8x16 | 6x16 + 3x14 | 35 | 2 | 138 | 15.5 | RE547-140 |
143 | 5 5/8 | 8x16 | 6x16 + 3x14 | 35 | 2 | 141 | 15.8 | RE547-143 |
146 | 5 3/4 | 8x16 | 6x16 + 3x14 | 35 | 2 | 144 | 16.3 | RE547-146 |
PR54 | ||||||||
Kode ROSCHEN: ROS RC 55 | ||||||||
Diameter | Tidak ada x Diameter tombol mm | Sudut tombol | Lubang flusing | Shroud Dia mm | Berat (kg) | Bagian No | ||
mm | inci | Tombol Pengukur | Tombol Depan | |||||
136 | 5 3/8 | 8x16 | 6x16 + 3x14 | 35 | 2 | 134 | 18.2 | PR54-136 |
140 | 5 1/2 | 8x16 | 6x16 + 3x14 | 35 | 2 | 138 | 18.5 | PR54-140 |
143 | 5 5/8 | 8x16 | 6x16 + 3x14 | 35 | 2 | 141 | 18.8 | PR54-143 |
146 | 5 3/4 | 8x16 | 6x16 + 3x14 | 35 | 2 | 144 | 19.2 | PR54-146 |
Catatan: Metzke, utas Remet tersedia! |
