Crawler Drilling Rig Machine For Air drilling , Air hammer drilling , Auger drilling , mud drilling

1 set
MOQ
Negotiate
harga
Crawler Drilling Rig Machine For Air drilling , Air hammer drilling , Auger drilling , mud drilling
fitur Galeri Deskripsi Produk Quote request suatu
fitur
Spesifikasi
Features: Geological Drilling
Model: Crawler Drilling Rig
Name: Mechanical Drive Crawler Drilling Rig
Functions: Air drilling, Air hammer drilling, Auger drilling, mud drilling
Use: Mineral exploration prospecting
Usage: Down Hole Drilling
Hammers: DTH Hammer
Tools: DTH Button Bits
Applications: Horizontal Drilling, Vertical or tile Drilling
Cahaya Tinggi:

rig pengeboran panas bumi

,

mesin pengeboran sumur

Informasi dasar
Tempat asal: CHINA
Nama merek: ROSCHEN
Sertifikasi: ISO
Nomor model: RS-C20
Syarat-syarat pembayaran & pengiriman
Kemasan rincian: Bundles
Menyediakan kemampuan: 10000 sets
Deskripsi Produk

Crawler Drilling Rig


Mechanical Drive Crawler Drilling Rig




Mechanical Drive Crawler Drilling Rig For Air drilling, Air hammer drilling, Auger drilling, mud drilling


RS-C20 Mechanical Drive Crawler Drilling Rig





Crawler Drilling Rig



We are providing Crawler Drilling Rigs which are equipped with automatic control system, and are primarily used for slope and straight holes drilling. These rigs of hydraulic transmissions are used for the exploration and prospecting of geology, metallurgy, nuke industry, coal industry, hydrology and various other industries. Bestowed with endurable strength, these products are also applied in railways, hydro-power industries etc. The products are available in various sizes, these can be horizontal, vertical or tile. Having strong-built looks, these products are energy saving and produce low sounds. Ideal for every arduous drilling task, these have high strength and accordant capabilities. These drill rigs of high versatility are well recognized for the their superior performance in mineral exploration drilling and geographical surveys drilling.







Salient Features:



1. Ruggedness and high stability, auto feed arrangement for easy and safe operation.

2. Multi-gear control and self-adaption technology.

3. Have extension mechanism in the output spindle of top drive, that tactfully protects all drilling tools.

4. Track-tension arrangement, husky structure for extra rigidity.






Product Description:


1. Drilling rig Characteristic:


With different combination methods,the rig has the function of air drilling, air hammer drilling, auger drilling, mud drilling for mineral exploration prospecting. It is suitable for beach, snow, grasslands, forest, swamps, the seasonal farmland etc. The drilling depth is 20meters.


It employs hydraulic driven, simple to use and easy to maintain. The machine selects the mature products of well-known specialised company of the world, for example: Kubota, Hawe, Stauff, Eaten, and do on guarantee the rig reliable.


The rubber crawler chassis is driven by hydraulic motor via gear box. It has high speed, low ground pressure, strong adaptability to ground surface. The hydraulic operation of chassis walking or rig can use the remote control or manual. It means the demand of vegetation protection and green construction.


The rig is powered by 14hp gasoline engine, it is the ideal power in field reducing fuel consumption.


Slide way type mast is made of rectangular section material slide plate by welded together.


The rig equipped new type power swivel, which separates the fluid circulation channel and the bearing shell, and which can reduce the probability of bearing damage.


Drilling tools hosting/pull down through roller chain system driven by a hydraulic motor. System adapt 12 A type sleeve roller chain to ensure the lifting power to meet the 1500kg at the same time safely and reliable.


Drill rig equipped with the weight balance system to ensure the rig working in the smooth movements, reliable safe and under load. The system sets the hydraulic balance valve and pressure relief valve.





Technical Specification:


Drilling method Depth(m) Pipe(diameter*length) (mm) The method of throwing dynamite Hole diameter
Mud drilling 20 Dia 60*1500 After moving the tools 3m, 3.5m
Air(Hammer) drilling 15 Dia 60*1500 After moving the tools Dia.: 82 mm
Casing drilling 10 Dia 50*1500 + Dia 102*1500 Center of the casing Dia.: 102 mm
Power swivel Rating torque 540 N.m
Rated speed 0 to 135 r/min
Hoisting/Push-down system Max. hoisting weight 1000 kg
Max. Push-down Force 2 kN
Max. hoisting speed 0.6 m/s
Hydraulic system Working pressure 180 bar
Engine power 14 hp / 3600r/min
Weight Chassis weight Less than 280kg
Total weight Less than 600 kg
Rubber crawler Dimension 1200X280X360X2
Ground pressure Less than 1.9 Psi
The Travel parameters Travel speed Forward 1.2 to 6.8 km/hour,four speed
Reverse 0.3 to 1.0 km/hour,two speed
Maximum traction force 50 N
Maximum load 400kg
Climbing angle 30%
Tilting slope More than 30°
Roll back angle More than 30°
Overall dimension About 2150*900*2650 /When working
About 2550*900*1450 /When moving
Piston mud pump Gasoline or diesel power option Pressure 14 bar
Displacement 120 L/min
Weight Less than 115 kg
Air screw compressor Total displacement 3.6 to 4.2 m3/min
Pressure 0.8 MPa
